- Frequency Range: 150 kHz to 250 MHz
- Rated Power Output: 100 watts into 2:1 VSWR
- Gain: 50 dB ±2 dB
- Input for rated output: 0 dBm (typical)
- Automatic Safety Shut-off: 140 watt
- Power Output @ 1 dB Compression Point: No Compression unit 100 W
Input:
- Impedance 50 ohms (nominal)
- VSWR: 1.7 (maximum
- Input Signal Modulation Compatibility: AM, FM, or Pulse modulation
- Connector: Type N on Front Panel
Output:
- Impedance: 50 ohms (nominal)
- VSWR: 1.7 (maximum)
- Harmonic distortion: 15 dBc at 50 watts
- Mismatch Tolerance: Automatic Safety Shut-off @ VSWR >7
- Connector: Type N on Front Panel
Power: (Universal)
- AC, Single Phase: 100-240 VAC 50/60 Hz
- Display and Interfaces: USB Remote Interface
- Front Panel Display (Column 1): Amplifier Current measurement Data
- Front Panel Display (Column 2): Amplifier Temperature measurement data
- Front Panel Display (Column 3): Load VSWR, RF Power Input/Output, Gain
- Remote Interlock (optional): 2-pin DIN
Mechanical:
- Cooling: Forced air (self-contained fans)
- Size: 19” Rack 4U
- Weight: 47 lbs (21.4 kg)
- Operating Temperature Range: 0° C to +40° C
