- 10MHz to 3600MHz or 6000MHz frequency range
- Resolution bandwidths from 300Hz to 10MHz (1:3:10)
- -120dBm typical noise floor at -40dBm ref. level/10kHz RBW
- Measurement in dBm or dBuV, mV or uW
- Zero span mode with AM and FM audio demodulation
- Trace modes of normal, peak hold and trace average
- Live, View and Reference traces in contrasting colors
- Twin markers with readout of absolute & difference values
- Smart marker movement with selectable peak tracking
- Frequency counter with down to 10Hz resolution
- Frequency presets and independent state storage
- Auto-find automatically sets sweep parameters for the highest signal found
- Unlimited storage for waveforms, set-ups and screens
- User assignable file names, file stamping from real-time clock
- USB interfaces for Flash drives and PC connection
- Comprehensive status and context sensitive help screens
- More than 3 hours continuous operation from a charge
- Smaller and lighter than other spectrum analyzers (weight only 0.56 kg)
** Additional features – with option U02:-
- NEW! High Resolution Scan Mode – up to 210,000 points with pan and zoom
- Limit lines and limit patterns with limits comparator
- Data logging of peak values, complete traces or screen images from timer, external trigger or limits comparator
- Automatic Measurements for CP, ACPR and OBW
- Waveform demodulation for AM and FM signals
- Sweep triggering from external trigger or limits comparator
- Compensation tables, fixed offsets and 75R compensation
- Custom Presets – fast change for repetitive setups
- Capability to show screen contents on a PC
